Wooden laser parts set Puri

As individual as yourself.

With the Puri, we present a variable fun model for all occasions. The tailless model with a wingspan of only 650 mm and a split surface is your new everyday companion in any terrain. The take-off weight is between 80 g and 140 g, depending on the version.

Your possibilities are almost limitless: You can build your Puri as a glider, with impeller drive or as a propeller version with various motors. The model also provides alternative drive options such as rocket motors, rubber motors or other bizarre ideas.

But as versatile as the model is, the construction is quite simple. Simple at it's best!

Which one is your Puri?

The set contains all parts precisely laser-cut from balsa and plywood, including the parts for the four different drive versions. In addition, the CFRP spars, connectors and rudder linkages are included as well as an overview drawing.

All that is still required is foil and the RC components.

Technical data:

• Wingspan: 650 mm

• Length: 260 mm

• Body-in-white weight: approx. 73 g

• Flight weight: 80 g to 160 g (depending on version)

• Wing area: 8 dm²

• Wing loading: 12,5 g/dm² to 20 g/dm²

• Motor: 5 g to 15 g

Recommended components (not included):

• EDF drive: Thrust Ø 30 mm

• Battery: 2s-LiPo with 200 mAh to 450 mAh

• Profile: MH60 mod.

• RC functions: Elevator, aileron, motor
