Laser parts set Mini Joe V2

The Mini Joe V2 is the evolution of the Mini Joe from 2015.

The simplified construction makes assembly even easier. The Mini Joe V2 is not an absolute meadow creeper. However, its flight behavior is always predictable. Anyone who can land a model aircraft safely will have no problems with the Mini Joe V2. Even slow flight is not critical, a stall is announced early on by "spongy behavior". With the 3s drive, powerful, dynamic aerobatics is possible and if you push the throttle stick forward, the model becomes quite fast. Half-throttle is enough for quiet, pleasurable cruising.

The enclosed construction plan was published in FMT 02/2023.

The laser parts set includes all components such as ribs and frames made of balsa and plywood in selected quality.

Technical specifications

• Wing span: 1,260mm
• Length (without spinner): 965 mm
• Wing area: 19.3 dm²
• Weight (ready to fly): 1,395 g (with 3s 2,500 mAh LiPo)
• Wing loading: 67 to 75 g/dm²
• Drive: Electric motors with a weight between approx. 100 and 150 g and a specific speed of approx. 900 to 1,000 kV
• Battery: 3s LiPo with 2,200-3,200 mAh

Components used

• Brushless: D-Power AL 35-09
• Prop: Schulze E-Prop 13×6"
• Battery: 3s 2500 mAh LiPo
• Values: current 37 A, 390 W

Adjustment data

• Center of gravity: 65 to 70 mm
• Rudder deflections: Aileron up/down 14 mm, Elevator up/down 15mm, Rudder on both sides 35 mm
